Thông số kỹ thuật
| Dimensions (W, H, L) | 53 mm x 32.5 mm x 140 mm 2.09 in x 1.28 in x 5.5 in |
|---|---|
| Data Rates | 10/100/100 Mbps |
| PoE Output | Pin Assignment and Polarity: 4/5 (+), 7/8 (-) Output Power Voltage 55 V DC User Port Power 30 Watts |
| Input Power Requirements | AC Input Voltage: 100 to 240 V AC AC Input Current: 0.67 A @ 100 – 240 V AC AC Frequency: 50 to 60 Hz |
| Weight | 0.44 lbs (200 g) |
| Connectors | Shielded RJ-45, EIA 568A and 568B |
| Operating Ambient Temperature | -4ºF to 104ºF (-20ºC to 40ºC) at 30 W -4ºF to 122ºF (-20ºC to 50ºC) at 25 W |
| Operating Humidity | Maximum 90%, Non-condensing |
| Storage Temperature | -4ºF to 158ºF (-20ºC to 70ºC) |
| Reliability | MTBF: 100,000 hrs @ 25ºC |
| Thermal Rating | 20 BTU/Hr @ 240 V AC |
| Regulatory Compliance | IEEE 802.3 at (PoE), China RoHS Compliant, WEEE Compliant, CE Compliant |
| Electromagnetic Emission and Immunity | FCC Part 15, Class B EN 55022 Class B (Emissions) EN 55024 (Immunity) VCCI |
| Safety | UL 60950-1 IEC/EN 60950-1 |
| Stacking restrictions | Do not stack. Do not bundle the power injector and AC power cable. |
